Moon by Simaudio Multi-Channel Power Amplifier - MC-8 Home Theater Amp (B)

Moon by Simaudio Multi-Channel Power Amplifier - MC-8 Home Theater Amp (B)

Moon by Simaudio Multi-Channel Power Amplifier - MC-8 Home Theater Amp (2-Tone)

Moon by Simaudio Multi-Channel Power Amplifier - MC-8 Home Theater Amp (S)

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audio One offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Call for Pricing
(416) 665-0749

Call for Pricing
(416) 665-0749

Call for Pricing
(416) 665-0749

Call for Pricing
(416) 665-0749

More options
Literature

Design features

  • Modular circuit design using plug-in cards for each channel’s circuitry, allowing for upgrades “in the field”.
  • Precision matched proprietary MOON output transistors for improved bass response and accurate sonic reproduction.
  • “Class A” power output to 5 watts for greater efficiency.
  • A very high damping factor for superior musical dynamics, improved signal speed and refined timbre accuracy.
  • Self-diagnostic system that detects both over-heating and the presence of DC in the input signal.
Specifications
Output Power at 8Ω 250 Watts per channel
Output Power at 4Ω 500 Watts per channel
Input Sensitivity 1420mV RMS
Input Impedance 24,900Ω
Gain 29dB
Signal-to-noise Ratio 105dB @ full power
Frequency response (full range) 10Hz - 100kHz +0/-3.0dB
THD (20Hz - 20kHz @ 1 watt) 0.02%
THD (20Hz - 20kHz @ 250 watts) 0.05%
Intermodulation distortion 0.005%
Shipping weight 240 lbs / 108 Kgs
Dimensions (width x height x depth) 17.4 x 13.4 x 21 in
