Details
| Sound (Speakers and Amplifier) | |
|---|---|
| Speaker type | Open Baffle Speaker |
| Sound (Processing) | |
| Dolby audio format support | Dolby Audio, Dolby Atmos |
| Simulated surround sound | - |
| Sound Modes | - |
| Picture (Panel) | |
| Backlight dimming type | Frame Dimming |
| Backlight type | Direct LED |
| Resolution | 3840 x 2160 |
| Sound (Processing) | |
| DTS audio format support | DTS Digital Surround, DTS Express, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS:X |
| Picture (Panel) | |
| Display type | LCD |
| Specification | |
| Frame color | Black |
| Design | |
| Stand design | Slim T Shape Stand |
| Built-in Tuner | |
| Tuner Channel Coverage (Digital Sat) | - |
| CI+ | - |
| Number of Tuners (Sat) | - |
| Number of Tuners (Terrestrial/Cable) | 1(Digital/Analog) |
| TV System (Digital Sat) | - |
| TV System (Digital Cable) | Clear QAM |
| Tuner Channel Coverage (Digital Cable) | CATV: 1-135 |
| Tuner Channel Coverage (Digital Terrestrial) | VHF: 2-13/UHF: 14-69 |
| TV System (Digital Terrestrial) | ATSC |
| TV System (Analog) | M |
| Tuner Channel Coverage (Analog) | VHF: 2-13/UHF: 14-69/CATV: 1-135 |
| Connectivity | |
| HDMI-CEC | Yes |
| Specification | |
| What's In The Box | Voice Remote Control (Supply): RMF-TX820U, Batteries: LR03, AC Power Cord Spec: Bundle (C7L) (US) (2pin) (flat blades), Operating Instructions: EN,FR,ES, Quick Setup Guide / Supplement CUE (GA): EN,FR,ES, Table Top Stand: Separate (Assembly required) |
| Connectivity | |
| USB playback codecs | MPEG1:MPEG1/MPEG2 PS:MPEG2/MPEG2 TS(HDV,AVCHD):MPEG2,MPEG4,AVC,AVS,HEVC/MP4(XAVC S):AVC,MPEG4,HEVC,AV1,VP8,WMV,MotionJpeg,/AVI:MotionJpeg,HEVC,MPEG4,WM |
| USB drive format support | Yes (Supported File System: FAT16/FAT32/NTFS) |
| Smartphone Connectivity - Screen Mirroring (Miracast™) | - |
| HDMI Audio Return Channel (ARC) | Yes (eARC/ARC) |
| Wi-Fi | Wi-Fi 6E |
| USB HDD Recording | - |
| USB drive format support | Yes (Supported File System: FAT16/FAT32/NTFS) |
| HDMI-CEC | Yes |
| HDCP | HDCP2.3(for HDMI1/2/3/4) |
| Bluetooth | Version 5.3,HID/HOGP/SPP/A2DP/AVRCP |
| RF (Terrestrial/Cable) Connection Input(s) | 1(Side) |
| IF (satellite) input(s) | - |
| Composite Video Input(s) | - |
| Component Video (Y/Pb/Pr) Input(s) | - |
| HDMI inputs total | 4(4Side) |
| Digital Audio (Outputs) | 1(Side) |
| USB ports | 2(Side) |
| Ethernet inputs | 1(Side) |
| RS-232C Input(s) | 1(Side)* * Only for the United States/Canada/Mexico/Dominican Republic models. |
| Smartphone Connectivity - Photo Sharing Plus / Photo Share | - |
| Smartphone Connectivity - Chromecast built-in | Yes |
| Audio / Headphone Output(s) | - |
