Ortofon Replacement Stylus - Stylus 30
Specifications | |
---|---|
Frequency range | 20-29.000 Hz |
Frequency response | 20-20.000 Hz + 2 / - 3 dB |
Tracking ability at 315Hz at recommended tracking force *) | 90 µm |
Compliance, dynamic, lateral | 25 µm/mN |
Stylus type | Nude Fine LIne |
Stylus tip radius | r/R 8/40 µm |
Equivalent stylus tip mass | 0,3 mg |
Tracking force range | 1.25-1.75 g (12.5-17.5 mN) |
Tracking force, recommended | 1.5 g (15 mN) |
Tracking angle | 20° |
Stylus colour | Black |
Recommended for following cartridges | Super OM 30, OM 30, OMP 30, OMB 30, LM 30, Concorde 30, SME 30H, LM 30H, TM 30H |
