NAD Phono Preamplifier - PP2e

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audio One offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Call for Pricing
(416) 665-0749

Literature

The PP 2e Phono Preamplifier offers superb performance in a clean and simple package. Perfect for the budget-conscious audiophile, the PP 2e’s moving coil/moving magnet input selector provides different phono cartridge options. This allows the PP 2e to be paired with any turntable, giving consumers unlimited choice in building their system. The PP 2e’s Auto Power Down feature saves energy by automatically powering the PP 2e to OFF when not in use. Built to be the best companion to one’s turntable setup, the PP 2e breathes life back into the vinyl you love.

IMPROVED ENERGY SAVING PHONO PREAMP

The PP 2e Phono Preamplifier offers superb performance in a clean and simple package for a very reasonable cost. Perfect for the budget-conscious audiophile, the PP 2e’s moving coil/moving magnet input selector provides different phono cartridge options. The PP 2e’s Auto Power Down feature saves energy by automatically powering the PP 2e to OFF when not in use.

  • Low noise, wide band MM & MC phono stage
  • Connect your turntable to almost all amplifiers and receivers
  • External 24 volt power supply
  • Gold plated input sockets
  • High quality components
  • LED power indicator
MC
Input Impedance (R and C)100 Ohm + 180pF
Gain at 1kHz60dB
Input Sensitivity (ref. 200mV output)0.3mV
Signal to Noise Ratio78dB (A weighted, with cartridge connected)
Input Overload (20Hz/1kHz/20kHz)0.8/9/84mV
Rated Distortion (THD 20Hz – 20kHz)<0.03%
RIAA Response Accuracy±0.3dB
MM
Input Impedance (R and C)47 kilohm + 200pF
Gain at 1kHz35dB
Input sensitivity (ref. 200mV output)2.5mV
Signal to Noise Ratio80dB (A weighted, with cartridge connected)
Input overload (20Hz/1kHz/20kHz)10/102/950mV
Rated Distortion (THD 20Hz – 20kHz)<0.03%
RIAA response accuracy±0.3dB
LINE OUT
Output Impedance100 Ohm
Maximum Output Level5.3V
General Specifications
AC SupplyExternal 23.5V DC
Dimensions excl. Power supply (W x H x D)135 x 49 x 72mm, 5 5/16 x 1 15/16 x 2 7/8″
